Name: High-Performance 78mm Wide Tire Single-Side Pressing Shaft Hub Motor for Heavy-Duty Lawn Mowers
Rating: 5.0 (50 reviews)

Product Parameters

The main parameters

Serial number	project	Specification	Remark
1	Motor diameter	270mm (including slight deviation in tire size)	The actual product shall prevail
2	Rated voltage	36V
3	Rated power	350W
4	Rated speed	500±50rpm
5	Rated current	8±0.5A
6	Maximum torque	15.9N/M
7	Hall Angle	120°
8	Number of magnetic poles	15 Antipodes	30 PCS
9	Shaft output method	Single-sided D-shaped roller mm
10	Lead length	300mm
11	Lead terminals	3+6 waterproof head
12	Braking method	electromagnetic brake
13	Steel shaft material	45cr
14	Waterproof grade	IP55
15	Maximum load	120kg
16	Environmental requirements	-20 to 65 degrees

Close

Product Details

Product Introduction

This hub motor is proudly developed by Shenzhen Jinhaixin Holding Co., Ltd. It features a 78mm wide tire design, which significantly enhances grip and stability on muddy and sloped lawns, preventing slippage. The single - side pressing shaft, combined with an optimized structure, greatly improves the load - bearing capacity of the shaft. Ideal for heavy - duty lawn mowers, it can resist bumps and prevent body shaking during high - speed cutting. The product has passed strict quality inspections and certifications, made of excellent materials, ensuring durability. We offer comprehensive after - sales support and technical assistance to international buyers, facilitating your business development.

Advantages and features

1. 78mm wide tire design provides excellent anti - slip performance on complex terrains. 2. Single - side pressing shaft structure optimizes load - bearing capacity. 3. Suitable for high - speed operation of heavy - duty lawn mowers, reducing bumps and body shaking. 4. High - quality materials and strict quality control ensure long - term durability.

Application Scenario

This hub motor is mainly suitable for heavy - duty lawn mowers used in large - scale lawn maintenance, such as golf courses, parks, and large - area gardens. It meets the needs of professional lawn care companies and large - scale property management companies.

Corporate Information

Shenzhen Jinhaixin Holdings Co., Ltd


Service Guarantee

Service Information

Tel

0755-28745009

Email

[email protected]

Address

Longgang District, Shenzhen, China

Call Now

Advisory Message

Pre-sales advice

1. Connect the motor to the controller and power supply according to the wiring diagram on the controller.
2. The tire is mounted on the outside of the outer rotor hub.
3. Power cords passing through metal parts should be protected with non-metallic materials.
4. Special Note: If the motor does not move, jams, or overheats rapidly when the drive powers on the motor, the power must be disconnected and the electrical angle or drive output adjusted within three seconds to avoid motor failure.
